2016 Ducati Monster 1200 R
Technical specification
Engine
Type Testastretta 11° DS, L-Twin cylinders, 4 valve per cylinder, Desmodromic, liquid cooled
Displacement 1198.4cc
Bore x Stroke 106 x 67.9mm
Compression ratio 13,0:1
▂ Power 117,7 kW (160 hp) @ 9,250 rpm
▂ Torque 131,4 Nm (97 lb-ft) @ 7,750 rpm
Technical data referring to power and torque was measured on an engine test stand at Ducati.
Fuel injection Synerject-Continental electronic fuel injection system, elliptical throttle body Ø 56 mm equivalent with full Ride-by-Wire
Exhaust Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers
Transmission
Gearbox 6 speed
Primary drive Straight cut gears, ratio 1.84:1
Ratio 1=37/15 2=30/17 3=27/20 4=24/22 5=23/24 6=22/25
Final drive Chain; Front sprocket 15; Rear sprocket 41
Clutch Wet, multi-plate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Chassis
Frame Tubular steel Trellis frame attached to the cylinder head
Front suspension Ohlins fully adjustable 48mm usd forks
Front wheel Tri-W spoke forged alloy 3.50" x 17"
Front Tyre Pirelli Diablo Supercorsa SP 120/70 ZR17
Rear suspension Progressive linkage with fully adjustable Öhlins monoshock. Aluminium single-sided swingarm
Rear wheel Tri-W spoke forged alloy 6.00" x 17"
Rear tyre Pirelli Diablo Supercorsa SP 200/55 ZR17
Front wheel travel 130mm (5.1in)
Rear wheel travel 159mm (6.2in)
Front brake 2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc evo M50 4-piston callipers, radial pump with ABS as standard
Rear brake 245 mm disc, 2-piston caliper, with ABS as standard
Instrumentation Full-TFT colour display
Dimensions and weight
Dry weight 180 kg (396,8 lb)
Weight data refers to the dry weight of the motorcycle without battery, lubricants and coolants for liquid-cooled models.
Wet weight (KERB) 207 kg (456,3 lb)
Kerb weights indicate total bike weight with all operating consumable liquids and a fuel tank filled to 90% of capacity (as per EC standard 93/93).
Seat height 830 mm (32,7 in)
Wheelbase 1509 mm (59.4 in)
Rake 24,3°
Trail 89 mm (3,5 in)
Fuel tank capacity 17.5l - (4.6 US gal)
Number of seats Dual seat
Equipments
Standard Equipment Riding modes,Power modes, DSP Ducati Safety Pack (ABS + DTC), RbW, seat cover
Warranty
Warranty 24 months unlimited mileage
Maintenance service intervals 15.000km (9.000m)/12 Months
Valve clearance check 30.000km (18,000m)
Emissions and Consumption
Standard Euro 4
Consumo ≥ 5,0 l/100 km - CO2 ≥ 117 g/km
